DFLS1200-7: High-Efficiency Schottky Rectifier for Power Applications

The DFLS1200-7, manufactured by Diodes Incorporated (USA), is a Schottky barrier rectifier designed to deliver high efficiency, low forward voltage drop, and excellent thermal stability. Packaged in a compact PowerDI™123 case, this diode is widely adopted in power supply, automotive, industrial, and consumer electronics designs.



Key Parameters

• Diode Type: Schottky Barrier Rectifier
• Reverse Voltage (VRRM): 120 V
• Forward Current (IF): 1 A continuous
• Forward Voltage Drop (VF): 0.75 V (typical at rated current)
• Reverse Leakage Current (IR): Very low, ensuring minimal power loss
• Package: PowerDI™123 – compact, thermally efficient surface-mount design
• Operating Temperature Range: –55°C to +150°C
• Compliance: RoHS and Green (Pb-free, halogen-free)

Key Features

• ✅ Low Forward Voltage Drop – Increases efficiency in DC/DC conversion and rectification.
• ✅ High Reverse Voltage (120 V) – Suitable for robust power system designs.
• ✅ Fast Recovery & Low Leakage – Reduces switching losses, improving overall performance.
• ✅ Thermally Efficient Package – PowerDI™123 design enhances heat dissipation and reliability.
• ✅ Compact & Robust – Ideal for high-density PCB layouts in modern electronics.



Application Scenarios

The DFLS1200-7 is engineered for power efficiency and reliability, making it suitable for:

1. Switch-Mode Power Supplies (SMPS) – Output rectification in AC-DC and DC-DC systems.
2. Consumer Electronics – Smartphones, tablets, and portable chargers.
3. Automotive Electronics – Power modules, LED lighting, infotainment, and ECU circuits.
4. Industrial Control Systems – Motor drivers, PLCs, and power regulation units.
5. Solar & Renewable Energy Systems – Efficient power conversion and rectification.

Why Source DFLS1200-7 from Sunether?

Our Advantages:

• 📦 In-Stock Availability – DFLS1200-7 is available in our warehouse for immediate delivery.
• 💲 Competitive Pricing – We leverage our strong sourcing channels to offer excellent cost savings.
• 🚀 Fast Shipping – Same-day or next-day dispatch to keep your production lines running smoothly.
• ✅ 100% Original Components – Authentic, manufacturer-traceable parts with strict quality control.
• 📋 Flexible Quantities – Support for both prototype orders and large-scale production.
• 🛠 Engineering & Supply Support – BOM analysis, cross-reference solutions, and expert technical guidance.

With Sunether, you benefit from real-time stock, competitive pricing, fast shipping, and expert support—ensuring your projects are always on schedule and cost-effective.📧 Contact Sunether today to check live stock and secure the best offer on the DFLS1200-7.
