DS26LV32ATM/NOPB: High-Speed, Low-Power RS-422 Line Receiver for Robust Data Communication

The DS26LV32ATM/NOPB is a high-performance quad differential line receiver manufactured by Texas Instruments (TI). Designed for balanced data communication standards such as RS-422 and RS-485, this device offers fast signal reception, wide common-mode voltage range, and excellent noise immunity. With its industrial-grade specifications and stable long-term availability, the DS26LV32ATM/NOPB remains a trusted component in industrial, automation, and communication systems.



Key Technical Specifications

• Part Type: Quad Differential Line Receiver
• Standard Support: RS-422 / RS-485 compatible
• Number of Receivers: 4 (quad package)
• Supply Voltage: 5 V ± 10%
• Receiver Logic: TTL/CMOS compatible outputs
• Input Common-Mode Voltage: –7 V to +12 V
• Data Rate: Up to 10 Mbps (typical)
• Package: SOIC-14 (ATM), RoHS-compliant and lead-free NOPB variant
• Operating Temperature: –40°C to +85°C (industrial)
• I/O Protection: ESD protection up to industry standards

Key Features & Advantages

✔ Wide Common-Mode Input Rang——The DS26LV32ATM/NOPB supports a broad input range (–7 V to +12 V), offering excellent immunity to ground shifts and enabling robust communication in noisy industrial environments.

✔ High-Speed Data Reception——With data rates up to 10 Mbps, this device is ideal for high-speed differential data links — commonly found in modern communication and control systems.

✔ Differential Receiver Architecture——Differential data reception significantly improves noise rejection and reliability over long cables or electrically noisy environments.

✔ TTL/CMOS Output Compatibility——Receivers interface directly with MCU, FPGA, DSP, or CPLD logic levels, simplifying system design without additional level translators.

✔ Industrial-Grade Robustness——Designed for extended temperature ranges and harsh conditions, the part meets the demands of factory automation, robotics, and mission-critical embedded controls.



Typical Application Scenarios

1. 🏭 Industrial Automation
2. 🛠 Building & Process Control
3. 📡 Data Acquisition & Instrumentation
4. 🚗 Non-Safety Automotive & Transportation
5. ⚙ Embedded & Communication Systems

Why Source DS26LV32ATM/NOPB from Sunether?

At Sunether, we understand that reliable sourcing is as important as technical performance — especially for components like quad line receivers that are critical to communication integrity and system uptime. Here’s what sets Sunether apart:

1. 📦 In-Stock Inventory Ready for Immediate Delivery
2. 💲 Competitive Global Pricing
3. 🚀 Fast & Reliable Shipping
4. ✅ Quality Assurance & Traceability
5. 🧠 Professional Technical & Procurement Support

By choosing Sunether as your sourcing partner, you gain:

✔ Stable and immediate component availability

✔ Competitive global pricing

✔ Fast and dependable delivery

✔ Expert technical and supply chain support



📩 Contact Sunether today to check live stock availability, request a competitive quote, or consult on component selection for your next communication or automation design.
