ES1C-E3/61T: High-Efficiency Ultra-Fast Rectifier for Power Applications

The ES1C-E3/61T, manufactured by Vishay Intertechnology (USA), is an ultra-fast recovery rectifier diode that combines compact packaging with excellent electrical performance. With its low reverse leakage, high efficiency, and fast switching speed, this device is a reliable solution for modern high-frequency power applications.



Key Parameters

• Diode Type: Ultra-Fast Recovery Rectifier
• Reverse Voltage (VRRM): 150 V
• Forward Current (IF): 1 A average
• Forward Voltage Drop (VF): ~0.95 V at rated current
• Reverse Recovery Time (trr): ~50 ns (ultra-fast switching)
• Reverse Leakage Current (IR): Very low, improving efficiency
• Package: SMA (DO-214AC) – compact, surface-mount, excellent thermal performance
• Operating Temperature Range: –55°C to +150°C
• Compliance: RoHS-compliant, halogen-free

Key Features

✅ Ultra-Fast Recovery Time – Minimizes switching losses in high-frequency applications.

✅ Low Reverse Leakage Current – Reduces power dissipation and improves efficiency.

✅ Robust SMA Package – Ensures excellent thermal management and mechanical stability.

✅ High Surge Current Capability – Provides reliability in demanding conditions.

✅ Environmentally Friendly – RoHS-compliant and halogen-free.



Application Scenarios

The ES1C-E3/61T is designed for power conversion and rectification in demanding electronic systems, including:

1. Switch-Mode Power Supplies (SMPS) – Output rectifiers for high-frequency DC/DC converters.
2. Consumer Electronics – Chargers, adapters, LED drivers, and set-top boxes.
3. Automotive Electronics – Infotainment systems, lighting modules, and auxiliary power units.
4. Industrial Control Systems – Robotics, automation controllers, and instrumentation.
5. Renewable Energy Systems – Solar inverters and battery charging units.

Why Source ES1C-E3/61T from Sunether?

Our Advantages:

📦 Ready-to-Ship Inventory – ES1C-E3/61T available in stock for immediate dispatch.

💲 Competitive Pricing – Strong global sourcing ensures the best cost advantage.

🚀 Fast Delivery – Same-day or next-day shipping to minimize downtime.

✅ 100% Authentic Parts – Manufacturer-certified with full traceability.

📋 Flexible Order Support – From small prototype runs to large-scale production.

🛠 Professional Service – BOM analysis, cross-reference sourcing, and technical support from industry experts.



With Sunether’s strong inventory, competitive pricing, rapid shipping, and expert service, you can count on us to keep your supply chain secure and efficient.📧 Contact Sunether today to secure stock and pricing advantages on the ES1C-E3/61T.
